SkyHawk TTU Premium Trailer Tracker

Who purchases the SkyHawk TTU Trailer Tracker?

  • Companies that require the very best in trailer tracking
  • Users that want the security of tracking trailer movement
  • Customers that typically perform their own vehicle maintenance

SkyHawk TTU Premium Features

  • Live tracking with tethered/un-tethered status, idle, and movement reporting
  • Real-time speed limit reporting when moving
  • 6 updates/day when un-tethered
  • Simple 2-wire installation by the customer or with installer network (extra cost)
  • Internal 6-month backup battery with illegal move alerting
  • Internal GPS recorder when out of cellular coverage—downloads automatically when coverage available
 Download Resources

Product Features:

  • Real-time tracking when tethered to power source
  • Passive tracking using 6-month internal, rechargeable battery with up to 6 updates per day
  • Internal antennas for concealed installation to thwart tampering
  • Certified by Wireless Carriers to ensure reliability.

Service Details:

  • 1, 2, 3, 4 or 6 updates per day
  • 2 min real-time updates when tethered
  • Reliable store and forward
  • 2,000 buffered messages
  • Latest Tracking Technologies
  • Low-battery notification
  • Over-the-air programming and firmware updates

Learn About Our Trailer Tracking Device Specs

This 50-channel GPS tracker for tractor trailers could be your key to maintaining trailer security and job efficiency. Whether your assets are on the move or parked at a job site, our tractor trailer tracker can keep you up to date on their whereabouts during and after business hours. The main specifications of the GPS tracker for trailers include:

  • 2-meter CEP location accuracy.
  • -160 dBm tracking sensitivity.
  • 3.8 Ah lithium-ion battery.
  • SMS and LTE data support.
  • Power Consumption <1mA @ 12Vdc Deep Sleep.
  • Operating voltage of 6-32 Vdc.
  • Weight of 0.6 pounds for easy transport and operation.
  • Operating temperatures of -30 to +5 degrees Celsius.
  • Storage temperatures of -40 to +85 degrees Celsius.
  • Full compliance with Restriction of Hazardous Substances (RoHS) standards.

How To Install a Trailer Tracking Device

Installing a trailer tracking device is quick and simple. Regardless of your business’s size or demands, it can be a great way to protect your assets. It takes only a few minutes to set up these devices, which helps you save money and implement new routines without any delays. These steps will help you install each device as quickly as possible so you can get back to work.

  • Choose a location for your device: You have some flexibility when placing your GPS trailer tracker. Ensure it’s in a secure place where the GPS can pick up a strong signal. Secure with the included, stainless fasteners.
  • Connect the proper wires: The next step is to establish a power connection. First, you’ll need to hook up the black wire to a secure ground point. Finally connect the red wire to a 12-volt source that is constant when the trailer is tethered.
  • Start tracking: After connecting the device, you can start receiving updates on your computer with our software’s help. By checking your alerts a few times a day, you can verify more frequently that your trailers are where they need to be.

The TYT Advantage – SkyHawk TTU Premium Trailer Tracker

When you’re transporting trailers over long distances, you need the ability to monitor them from afar. These are high-value assets and may also contain expensive cargo that you want to protect. With a GPS tracking device for tractor trailers, you can monitor your trailers from almost any location. Our commercial trailer tracking systems allow you to receive real-time information when the unit is tethered, as well as multiple location updates a day when untethered.

As a provider of the semi trailer tracking systems, we can help you stay up to date with current industry standards. In the long run, you can even increase productivity and prevent damages caused by theft.
